XRCGE26M000FBA2AR0,日产村田晶振,2016贴片晶振,村田无源晶振,车规温度,日本Murata晶振

原厂型号 Original model ：	XRCGE26M000FBA2AR0
品牌 brand ：	村田Murata
型号名称 Model name：	XRCFD
Type 系列：	MHz晶振
频率 frequency ：	26 MHz
Frequency Stability频率稳定度	±35ppm
frequency tolerance 频率容差	±15ppm
Load capacitance 负载电容	8pF
Size / Dimension 尺寸	2.00mm x 1.60mm

订购热线：0755-27838351

XRCGE26M000FBA2AR0,日产村田晶振,2016贴片晶振,村田无源晶振,车规温度,日本Murata晶振

原厂型号 Original model ：	XRCGE26M000FBA2AR0	品牌 brand ：	Murata Electronics
品牌 brand ：	村田Murata	ESR (Equivalent Series Resistance)ESR（等效串联电阻）	60 Ohms
型号名称 Model name：	XRCFD	Operating Temperature温度	-40°C~125°C
Type 系列：	MHz Crystal	Termination 脚位	4 pad
频率 frequency ：	26 MHz	Package Type 封装类型	4-SMD
Frequency Stability频率稳定度	±35ppm	Package Height 高度	0.70mm
frequency tolerance 频率容差	±15ppm	最小包装数 MPQ ：	3000 / reel
Load capacitance 负载电容	8pF	Packaging 包装	Tape and Reel
Size / Dimension 尺寸	2.00mm x 1.60mm	Mounting Style 安装方式	Surface Mount

XRCGE26M000FBA2AR0,日产村田晶振,2016贴片晶振,村田无源晶振,车规温度,日本Murata晶振

XRCTD32M000N1P1AR0	村田Murata	XRCTD	MHz Crystal	32 MHz	±20ppm	±10ppm	6pF	120 Ohms	-30°C~85°C	4-SMD
XRCGE26M000FBA2AR0	村田Murata	XRCFD	MHz Crystal	26 MHz	±35ppm	±15ppm	8pF	60 Ohms	-40°C~125°C	4-SMD
XRCGE24M000FBA1BR0	村田Murata	XRCGE	MHz Crystal	24 MHz	±35ppm	±15ppm	8pF	120 Ohms	-40°C~125°C	4-SMD
XRCGB40M000F5A12R0	村田Murata	XRCGB	MHz Crystal	40 MHz	±65ppm	±50ppm	6pF	60 Ohms	-40°C~125°C	4-SMD
XRCMD48M000F1P2AR0	村田Murata	XRCFD	MHz Crystal	48 MHz	±20ppm	±10ppm	7pF	40 Ohms	-40°C~85°C	4-SMD
XRCGE25M000FBA1BR0	村田Murata	XRCGE	MHz Crystal	25 MHz	±35ppm	±15ppm	8pF	100 Ohms	-40°C~125°C	4-SMD
XRCGE40M000F3A1BR0	村田Murata	XRCGE	MHz Crystal	40 MHz	±45ppm	±30ppm	8pF	70 Ohms	-40°C~125°C	4-SMD
XRCGE27M000F2A1AR0	村田Murata	XRCGE	MHz Crystal	27 MHz	±35ppm	±20ppm	6pF	80 Ohms	-40°C~125°C	4-SMD
XRCGE50M000F5A2AR0	村田Murata	XRCGE	MHz Crystal	50 MHz	±50ppm	±50ppm	4.7pF	50 Ohms	-40°C~125°C	4-SMD
XRCGE50M000F3A1AR0	村田Murata	XRCGE	MHz Crystal	50 MHz	±45ppm	±30ppm	6pF	50 Ohms	-40°C~125°C	4-SMD
XRCGE20M000F3A1BR0	村田Murata	XRCFD	MHz Crystal	20 MHz	±45ppm	±30ppm	8pF	150 Ohms	-40°C~125°C	4-SMD
XRCED38M400FXQ50R0	村田Murata	-	MHz Crystal	38.4 MHz	±20ppm	±20ppm	10pF	80 Ohms	-30°C~85°C	4-SMD
XRCMD32M000FXP53R0	村田Murata	XRCMD	MHz Crystal	32 MHz	±20ppm	±30ppm	6pF	80 Ohms	-40°C~85°C	4-SMD
XRCFD26M000FYQ53R0	村田Murata	-	MHz Crystal	26 MHz	±20ppm	±20ppm	8pF	150 Ohms	-30°C~85°C	4-SMD
WMRAG32K76CS4C00R0	村田Murata	-	MEMS	32.768 kHz	-	±20ppm	8pF	75 kOhms	-40°C~125°C	4-SMD
WMRAG32K76CS2C00R0	村田Murata	-	MEMS	32.768 kHz	-	±20ppm	8pF	75 kOhms	-40°C~85°C	4-SMD
XRCGB27M000FAN00R0	村田Murata	XRCGB	MHz Crystal	27 MHz	±25ppm	±25ppm	6pF	150 Ohms	-10°C~70°C	4-SMD
XRCGB48M000F0L00R0	村田Murata	XRCGB	MHz Crystal	48 MHz	±50ppm	±100ppm	6pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB24M000F2P29R0	村田Murata	XRCGB	MHz Crystal	24 MHz	±20ppm	±20ppm	8pF	80 Ohms	-30°C~85°C	4-SMD
XRCGB24M000F1H03R0	村田Murata	-	MHz Crystal	24 MHz	±10ppm	±10ppm	12pF	80 Ohms	-20°C~70°C	4-SMD
XRCGB25M000F1H02R0	村田Murata	-	MHz Crystal	25 MHz	±10ppm	±10ppm	10pF	80 Ohms	-20°C~70°C	4-SMD
XRCGB32M000F1H2AR0	村田Murata	XRCGB	MHz Crystal	32 MHz	±20ppm	±20ppm	10pF	60 Ohms	-40°C~105°C	4-SMD
XRCGB24M000F1H00R0	村田Murata	XRCGB	MHz Crystal	24 MHz	±10ppm	±10ppm	6pF	80 Ohms	-20°C~70°C	4-SMD
XRCGB24M000F1H17R0	村田Murata	-	MHz Crystal	24 MHz	±35ppm	±10ppm	6pF	80 Ohms	-40°C~110°C	4-SMD
XRCGB32M000F1H17R0	村田Murata	XRCGB	MHz Crystal	32 MHz	±10ppm	±10ppm	9pF	40 Ohms	-30°C~85°C	4-SMD
XRCGB27M000F3A00R0	村田Murata	XRCGB	MHz Crystal	27 MHz	±35ppm	±30ppm	6pF	80 Ohms	-40°C~125°C	4-SMD
XRCGB26M000F2P00R0	村田Murata	XRCGB	MHz Crystal	26 MHz	±20ppm	±20ppm	6pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB16M000FXN01R0	村田Murata	-	MHz Crystal	16 MHz	±40ppm	±40ppm	8pF	200 Ohms	-30°C~85°C	4-SMD
XRCGB24M000FBP12R0	村田Murata	-	MHz Crystal	24 MHz	±20ppm	±15ppm	6pF	80 Ohms	-30°C~85°C	4-SMD
XRCGB27M000F0L00R0	村田Murata	XRCGB	MHz Crystal	27 MHz	±50ppm	±100ppm	6pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB30M000F0L00R0	村田Murata	XRCGB	MHz Crystal	30 MHz	±50ppm	±100ppm	6pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB30M000F0Z00R0	村田Murata	-	MHz Crystal	30 MHz	±100ppm	±100ppm	6pF	100 Ohms	-40°C~105°C	4-SMD
XRCGB31M250F0L00R0	村田Murata	-	MHz Crystal	31.25 MHz	±50ppm	±100ppm	6pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB31M250F0Z00R0	村田Murata	-	MHz Crystal	31.25 MHz	±100ppm	±100ppm	6pF	100 Ohms	-40°C~105°C	4-SMD
XRCGB33M868F4M01R0	村田Murata	-	MHz Crystal	33.8688 MHz	±40ppm	±45ppm	8pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB33M868F4M02R0	村田Murata	-	MHz Crystal	33.8688 MHz	±40ppm	±45ppm	10pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB48M000F4M01R0	村田Murata	-	MHz Crystal	48 MHz	±40ppm	±45ppm	8pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB48M000F4M02R0	村田Murata	-	MHz Crystal	48 MHz	±40ppm	±45ppm	10pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB50M000F0L00R0	村田Murata	-	MHz Crystal	50 MHz	±50ppm	±100ppm	6pF	60 Ohms	-30°C~85°C	4-SMD
XRCGB24M576F3M01R0	村田Murata	-	MHz Crystal	24.576 MHz	±40ppm	±30ppm	8pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB24M576F3M02R0	村田Murata	-	MHz Crystal	24.576 MHz	±40ppm	±30ppm	10pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB27M120F3M01R0	村田Murata	-	MHz Crystal	27.12 MHz	±40ppm	±30ppm	8pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB31M250F3M00R0	村田Murata	-	MHz Crystal	31.25 MHz	±40ppm	±30ppm	6pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB27M000F3M14R0	村田Murata	XRCGB	MHz Crystal	27 MHz	±40ppm	±30ppm	6pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB27M000F2P00R0	村田Murata	XRCGB	MHz Crystal	27 MHz	±20ppm	±20ppm	6pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB25M000F2P01R0	村田Murata	-	MHz Crystal	25 MHz	±20ppm	±20ppm	8pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB26M000F2P02R0	村田Murata	-	MHz Crystal	26 MHz	±20ppm	±20ppm	10pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB27M000F2P01R0	村田Murata	-	MHz Crystal	27 MHz	±20ppm	±20ppm	8pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB27M000F2P02R0	村田Murata	-	MHz Crystal	27 MHz	±20ppm	±20ppm	10pF	150 Ohms	-30°C~85°C	4-SMD
XRCGB30M000F2P01R0	村田Murata	-	MHz Crystal	30 MHz	±20ppm	±20ppm	8pF	100 Ohms	-30°C~85°C	4-SMD
XRCGB30M000F2P02R0	村田Murata	-	MHz Crystal	30 MHz	±20ppm	±20ppm	10pF	100 Ohms	-30°C~85°C	4-SMD
XRCPB24M000F0Z00R0	村田Murata	XRCPB	MHz Crystal	24 MHz	±100ppm	±100ppm	6pF	150 Ohms	-40°C~105°C	4-SMD
XRCPB24M000F2P00R0	村田Murata	XRCPB	MHz Crystal	24 MHz	±20ppm	±20ppm	6pF	150 Ohms	-30°C~85°C	4-SMD
XRCPB24M576F0L00R0	村田Murata	XRCPB	MHz Crystal	24.576 MHz	±50ppm	±100ppm	6pF	150 Ohms	-30°C~85°C	4-SMD
XRCPB25M000F0Z00R0	村田Murata	XRCPB	MHz Crystal	25 MHz	±100ppm	±100ppm	6pF	150 Ohms	-40°C~105°C	4-SMD
XRCPB25M000F3M00R0	村田Murata	XRCPB	MHz Crystal	25 MHz	±40ppm	±30ppm	6pF	150 Ohms	-30°C~85°C	4-SMD
XRCPB27M000F2P00R0	村田Murata	XRCPB	MHz Crystal	27 MHz	±20ppm	±20ppm	6pF	150 Ohms	-30°C~85°C	4-SMD
XRCPB32M000F0L00R0	村田Murata	XRCPB	MHz Crystal	32 MHz	±50ppm	±100ppm	6pF	100 Ohms	-30°C~85°C	4-SMD
XRCPB40M000F0L00R0	村田Murata	XRCPB	MHz Crystal	40 MHz	±50ppm	±100ppm	6pF	100 Ohms	-30°C~85°C	4-SMD
XRCPB48M000F4M00R0	村田Murata	XRCPB	MHz Crystal	48 MHz	±40ppm	±45ppm	6pF	100 Ohms	-30°C~85°C	4-SMD
