FCX7M01228820Y5D,Fujicom富士通无源晶振,FCX-7M贴片晶振

原厂型号 Original model ：	FCX7M01228820Y5D
品牌 brand ：	Fujicom晶振
型号名称 Model name：	FCX-7M
Type 系列：	MHz Crystal
频率 frequency ：	12.288 MHz
Frequency Stability频率稳定度	±10ppm
frequency tolerance频率容差	±30ppm
Load capacitance 负载电容	20pF
Size / Dimension 尺寸	7050石英贴片晶振

订购热线：0755-27838351

FCX7M01228820Y5D,Fujicom富士通无源晶振,FCX-7M贴片晶振

原厂型号 Original model ：	FCX7M01228820Y5D	品牌 brand ：	Fujicom晶振
品牌 brand ：	Fujicom晶振	ESR（等效串联电阻）ESR (Equivalent Series Resistance)	40 Ohms
型号名称 Model name：	FCX-7M贴片晶振	温度 Operating Temperature	-40°C ~ 85°C
Type 系列：	MHz Crystal	脚位 Termination：	4 pad
频率 frequency ：	12.288 MHz	封装类型 Package Type：	4-SMD
Frequency Stability频率稳定度	±10ppm	高度 Package Height：	1.10mm
frequency tolerance频率容差	±30ppm	最小包装数 MPQ ：	-
Load capacitance 负载电容	20pF	包装 Packaging：	Tape and Reel
Size / Dimension 尺寸	7.00mm x 5.00mm	安装方式 Mounting Style：	Surface Mount

FCX7M01228820Y5D,Fujicom富士通无源晶振,FCX-7M贴片晶振

FCX7M01228820Y5D	Fujicom晶振	FCX-7M	MHz Crystal	12.288 MHz	±10ppm	±30ppm	20pF
FCX7M00163818Y5J	Fujicom晶振	FCX-7M	MHz Crystal	16.384 MHz	±30ppm	±30ppm	18pF
FCX7M01200016Y5D	Fujicom晶振	FCX-7M	MHz Crystal	12 MHz	±10ppm	±30ppm	16pF
FCX7M01431808E2G	Fujicom晶振	FCX-7M	MHz Crystal	14.31818 MHz	±20ppm	±15ppm	8pF
FCX7M01693420Y5D	Fujicom晶振	FCX-7M	MHz Crystal	16.9344 MHz	±10ppm	±30ppm	20pF
FCX7M02500016Y1J	Fujicom晶振	FCX-7M	MHz Crystal	25 MHz	±30ppm	±10ppm	16pF
FCX7M01843208Y2J	Fujicom晶振	FCX-7M	MHz Crystal	18.432 MHz	±30ppm	±15ppm	8pF
FCX7M01105912Y2J	Fujicom晶振	FCX-7M	MHz Crystal	11.0592 MHz	±30ppm	±15ppm	12pF
FCX7M01105910E2G	Fujicom晶振	FCX-7M	MHz Crystal	11.0592 MHz	±20ppm	±15ppm	10pF
FCX7M04800010Y1J	Fujicom晶振	FCX-7M	MHz Crystal	48 MHz	±30ppm	±10ppm	10pF
FCX7M01843218Y5D	Fujicom晶振	FCX-7M	MHz Crystal	18.432 MHz	±10ppm	±30ppm	18pF
FCX7M01250012E2G	Fujicom晶振	FCX-7M	MHz Crystal	12.5 MHz	±20ppm	±15ppm	12pF
FCX7M04800015Y5D	Fujicom晶振	FCX-7M	MHz Crystal	48 MHz	±10ppm	±30ppm	15pF
FCX7M04800020Y5D	Fujicom晶振	FCX-7M	MHz Crystal	48 MHz	±10ppm	±30ppm	20pF
FCX7M00163810Y5J	Fujicom晶振	FCX-7M	MHz Crystal	16.384 MHz	±30ppm	±30ppm	10pF
FCX7M03600008E2G	Fujicom晶振	FCX-7M	MHz Crystal	36 MHz	±20ppm	±15ppm	8pF
FCX7M00960018Y5D	Fujicom晶振	FCX-7M	MHz Crystal	9.6 MHz	±10ppm	±30ppm	18pF
FCX7M01693420Y1J	Fujicom晶振	FCX-7M	MHz Crystal	16.9344 MHz	±30ppm	±10ppm	20pF
FCX7M03600016Y5J	Fujicom晶振	FCX-7M	MHz Crystal	36 MHz	±30ppm	±30ppm	16pF
FCX7M00800018E3L	Fujicom晶振	FCX-7M	MHz Crystal	8 MHz	±50ppm	±20ppm	18pF
FCX7M00960010Y2J	Fujicom晶振	FCX-7M	MHz Crystal	9.6 MHz	±30ppm	±15ppm	10pF
FCX7M02500016Y5D	Fujicom晶振	FCX-7M	MHz Crystal	25 MHz	±10ppm	±30ppm	16pF
FCX7M05000008E2G	Fujicom晶振	FCX-7M	MHz Crystal	50 MHz	±20ppm	±15ppm	8pF
FCX7M00800030Y5J	Fujicom晶振	FCX-7M	MHz Crystal	8 MHz	±30ppm	±30ppm	30pF
FCX7M01200012Y5D	Fujicom晶振	FCX-7M	MHz Crystal	12 MHz	±10ppm	±30ppm	12pF
FCX7M01200018Y5J	Fujicom晶振	FCX-7M	MHz Crystal	12 MHz	±30ppm	±30ppm	18pF
FCX7M01693418Y1J	Fujicom晶振	FCX-7M	MHz Crystal	16.9344 MHz	±30ppm	±10ppm	18pF
FCX7M01693408Y2J	Fujicom晶振	FCX-7M	MHz Crystal	16.9344 MHz	±30ppm	±15ppm	8pF
FCX7M00960018Y1J	Fujicom晶振	FCX-7M	MHz Crystal	9.6 MHz	±30ppm	±10ppm	18pF
FCX7M00800016Y5L	Fujicom晶振	FCX-7M	MHz Crystal	8 MHz	±50ppm	±30ppm	16pF
FCX7M00184316Y5J	Fujicom晶振	FCX-7M	MHz Crystal	18.432 MHz	±30ppm	±30ppm	16pF
FCX7M00800020Y1J	Fujicom晶振	FCX-7M	MHz Crystal	8 MHz	±30ppm	±10ppm	20pF
FCX7M03600018Y5D	Fujicom晶振	FCX-7M	MHz Crystal	36 MHz	±10ppm	±30ppm	18pF
FCX7M00800012Y2J	Fujicom晶振	FCX-7M	MHz Crystal	8 MHz	±30ppm	±15ppm	12pF
FCX7M02500012Y5D	Fujicom晶振	FCX-7M	MHz Crystal	25 MHz	±10ppm	±30ppm	12pF
FCX7M00960008Y2J	Fujicom晶振	FCX-7M	MHz Crystal	9.6 MHz	±30ppm	±15ppm	8pF
FCX7M01431808Y2J	Fujicom晶振	FCX-7M	MHz Crystal	14.31818 MHz	±30ppm	±15ppm	8pF
FCX7M02500012E2G	Fujicom晶振	FCX-7M	MHz Crystal	25 MHz	±20ppm	±15ppm	12pF
FCX7M00960012Y2J	Fujicom晶振	FCX-7M	MHz Crystal	9.6 MHz	±30ppm	±15ppm	12pF
FCX7M00221108Y5J	Fujicom晶振	FCX-7M	MHz Crystal	22.1184 MHz	±30ppm	±30ppm	8pF
FCX7M03600020Y1J	Fujicom晶振	FCX-7M	MHz Crystal	36 MHz	±30ppm	±10ppm	20pF
FCX7M01693410E2G	Fujicom晶振	FCX-7M	MHz Crystal	16.9344 MHz	±20ppm	±15ppm	10pF
FCX7M00800018I5Z	Fujicom晶振	FCX-7M	MHz Crystal	8 MHz	±100ppm	±30ppm	18pF
FCX7M00110510Y5J	Fujicom晶振	FCX-7M	MHz Crystal	11.0592 MHz	±30ppm	±30ppm	10pF
FCX7M00110508Y5J	Fujicom晶振	FCX-7M	MHz Crystal	11.0592 MHz	±30ppm	±30ppm	8pF
FCX7M01600018Y1J	Fujicom晶振	FCX-7M	MHz Crystal	16 MHz	±30ppm	±10ppm	18pF
FCX7M00169308Y5J	Fujicom晶振	FCX-7M	MHz Crystal	16.9344 MHz	±30ppm	±30ppm	8pF
FCX7M04800010Y5D	Fujicom晶振	FCX-7M	MHz Crystal	48 MHz	±10ppm	±30ppm	10pF
FCX7M01843215Y1J	Fujicom晶振	FCX-7M	MHz Crystal	18.432 MHz	±30ppm	±10ppm	15pF
FCX7M05000008Y2J	Fujicom晶振	FCX-7M	MHz Crystal	50 MHz	±30ppm	±15ppm	8pF
FCX7M01200018E3L	Fujicom晶振	FCX-7M	MHz Crystal	12 MHz	±50ppm	±20ppm	18pF
FCX7M00800018Y5D	Fujicom晶振	FCX-7M	MHz Crystal	8 MHz	±10ppm	±30ppm	18pF
FCX7M03600020Y5J	Fujicom晶振	FCX-7M	MHz Crystal	36 MHz	±30ppm	±30ppm	20pF
FCX7M02500010Y2J	Fujicom晶振	FCX-7M	MHz Crystal	25 MHz	±30ppm	±15ppm	10pF
FCX7M03600020Y5D	Fujicom晶振	FCX-7M	MHz Crystal	36 MHz	±10ppm	±30ppm	20pF
FCX7M00163830Y5J	Fujicom晶振	FCX-7M	MHz Crystal	16.384 MHz	±30ppm	±30ppm	30pF
FCX7M03600012Y2J	Fujicom晶振	FCX-7M	MHz Crystal	36 MHz	±30ppm	±15ppm	12pF
FCX7M04800018Y5D	Fujicom晶振	FCX-7M	MHz Crystal	48 MHz	±10ppm	±30ppm	18pF
FCX7M02500020Y1J	Fujicom晶振	FCX-7M	MHz Crystal	25 MHz	±30ppm	±10ppm	20pF
FCX7M00800012Y5J	Fujicom晶振	FCX-7M	MHz Crystal	8 MHz	±30ppm	±30ppm	12pF
