ECS-.327-12.5-12-TR,ECS无源晶振,ECX-12黑色面陶瓷晶振

原厂型号 Original model ：	ECS-.327-12.5-12-TR
品牌 brand ：	ECS晶振
型号名称 Model name：	ECX-12
Type 系列：	kHz Crystal (Tuning Fork)
频率 frequency ：	32.768kHz
Frequency Stability频率稳定度	-
frequency tolerance频率容差	±20ppm
Load capacitance 负载电容	12.5pF
Size / Dimension 尺寸	2.00mm x 1.20mm

订购热线：0755-27838351

ECS-.327-12.5-12-TR,ECS无源晶振,ECX-12黑色面陶瓷晶振

原厂型号 Original model ：	ECS-.327-12.5-12-TR	品牌 brand ：	ECS伊西斯无源晶振
品牌 brand ：	ECS晶振	ESR（等效串联电阻）ESR (Equivalent Series Resistance)	90 kOhm
型号名称 Model name：	ECX-12	温度 Operating Temperature	-40°C ~ 85°C
Type 系列：	kHz Crystal (Tuning Fork)	脚位 Termination：	2 pad
频率 frequency ：	32.768kHz	封装类型 Package Type：	2-SMD
Frequency Stability频率稳定度	-	高度 Package Height：	0.6mm
frequency tolerance频率容差	±20ppm	最小包装数 MPQ ：	-
Load capacitance 负载电容	12.5pF	包装 Packaging：	Tape and Reel
Size / Dimension 尺寸	2.00mm x 1.20mm	安装方式 Mounting Style：	Surface Mount

ECS-.327-12.5-12-TR,ECS无源晶振,ECX-12黑色面陶瓷晶振

ECS-.327-12.5-12-TR	ECX-12	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	12.5pF	90 kOhm
ECS-.327-6-12-TR	ECX-12	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	6pF	90 kOhm
ECS-.327-7-12-TR	ECX-12	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	7pF	90 kOhm
ECS-.327-9-12-TR	ECX-12	kHz Crystal (Tuning Fork)	32.768k晶体	-	±20ppm	9pF	90 kOhm
ECS-240-8-47-JTN-TR	ECX-1247	MHz Crystal	24MHz	±20ppm	±20ppm	8pF	150 Ohm
ECS-260-8-47-JTN-TR	ECX-1247	MHz Crystal	26MHz	±20ppm	±20ppm	8pF	150 Ohm
ECS-320-8-47-JTN-TR	ECX-1247	MHz Crystal	32MHz	±20ppm	±20ppm	8pF	100 Ohm
ECS-360-8-47-JTN-TR	ECX-1247	MHz Crystal	36MHz	±20ppm	±20ppm	8pF	100 Ohm
ECS-400-8-47-JTN-TR	ECX-1247	MHz Crystal	40MHz	±20ppm	±20ppm	8pF	80 Ohm
ECS-480-8-47-JTN-TR	ECX-1247	MHz Crystal	48MHz	±20ppm	±20ppm	8pF	80 Ohm
ECS-200-8-37CKM	ECX-1637	MHz Crystal	20MHz	±10ppm	±10ppm	8pF	100 Ohm
ECS-240-8-37CKM	ECX-1637	MHz Crystal	24MHz	±10ppm	±10ppm	8pF	80 Ohm
ECS-250-8-37CKM	ECX-1637	MHz Crystal	25MHz	±10ppm	±10ppm	8pF	80 Ohm
ECS-260-8-37CKM	ECX-1637	MHz Crystal	26MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-270-8-37CKM	ECX-1637	MHz Crystal	27MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-300-8-37CKM	ECX-1637	MHz Crystal	30MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-320-8-37CKM	ECX-1637	MHz Crystal	32MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-360-8-37CKM	ECX-1637	MHz Crystal	36MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-400-8-37CKM	ECX-1637	MHz Crystal	40MHz	±10ppm	±10ppm	8pF	50 Ohm
ECS-100-S-19A-TR	ECX-19A	MHz Crystal	10MHz	±50ppm	±30ppm	Series	80 Ohm
ECS-110.5-20-19A-TR	ECX-19A	MHz Crystal	11.0592MHz	±50ppm	±30ppm	20pF	80 Ohm
ECS-120-20-19A-TR	ECX-19A	MHz Crystal	12MHz	±50ppm	±30ppm	20pF	80 Ohm
ECS-120-S-19A-TR	ECX-19A	MHz Crystal	12MHz	±50ppm	±30ppm	Series	80 Ohm
ECS-143-20-19A-TR	ECX-19A	MHz Crystal	14.31818MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-143-S-19A-TR	ECX-19A	MHz Crystal	14.31818MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-160-S-19A-TR	ECX-19A	MHz Crystal	16MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-184-S-19A-TR	ECX-19A	MHz Crystal	18.432MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-196.6-S-19A-TR	ECX-19A	MHz Crystal	19.6608MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-200-20-19A-TR	ECX-19A	MHz Crystal	20MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-200-S-19A-TR	ECX-19A	MHz Crystal	20MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-240-20-19A-TR	ECX-19A	MHz Crystal	24MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-240-S-19A-TR	ECX-19A	MHz Crystal	24MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-35-17-19A-TR	ECX-19A	MHz Crystal	3.579545MHz	±50ppm	±30ppm	17pF	200 Ohm
ECS-36-20-19A-TR	ECX-19A	MHz Crystal	3.6864MHz	±50ppm	±30ppm	20pF	200 Ohm
ECS-40-20-19A-TR	ECX-19A	MHz Crystal	4MHz	±50ppm	±30ppm	20pF	150 Ohm
ECS-49-20-19A-TR	ECX-19A	MHz Crystal	4.9152MHz	±50ppm	±30ppm	20pF	150 Ohm
ECS-61-32-19A-TR	ECX-19A	MHz Crystal	6.144MHz	±50ppm	±30ppm	32pF	100 Ohm
ECS-73-20-19A-TR	ECX-19A	MHz Crystal	7.3728MHz	±50ppm	±30ppm	20pF	100 Ohm
ECS-80-20-19A-TR	ECX-19A	MHz Crystal	8MHz	±50ppm	±30ppm	20pF	100 Ohm
ECS-98.3-20-19A-TR	ECX-19A	MHz Crystal	9.8304MHz	±50ppm	±30ppm	20pF	100 Ohm
ECS-160-8-36CKM	ECX-2236	MHz Crystal	16MHz	±10ppm	±10ppm	8pF	80 Ohm
ECS-184-8-36CKM	ECX-2236	MHz Crystal	18.432MHz	±10ppm	±10ppm	8pF	80 Ohm
ECS-192-8-36CKM	ECX-2236	MHz Crystal	19.2MHz	±10ppm	±10ppm	8pF	80 Ohm
ECS-196-8-36CKM	ECX-2236	MHz Crystal	19.6608MHz	±10ppm	±10ppm	8pF	80 Ohm
ECS-200-8-36CKM	ECX-2236	MHz Crystal	20MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-240-8-36CKM	ECX-2236	MHz Crystal	24MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-245.7-8-36CKM	ECX-2236	MHz Crystal	24.576MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-250-8-36CKM	ECX-2236	MHz Crystal	25MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-260-8-36CKM	ECX-2236	MHz Crystal	26MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-270-8-36CKM	ECX-2236	MHz Crystal	27MHz	±10ppm	±10ppm	8pF	60 Ohm
ECS-300-8-36CKM	ECX-2236	MHz Crystal	30MHz	±10ppm	±10ppm	8pF	50 Ohm
ECS-320-8-36CKM	ECX-2236	MHz Crystal	32MHz	±10ppm	±10ppm	8pF	50 Ohm
ECS-360-8-36CKM	ECX-2236	MHz Crystal	36MHz	±10ppm	±10ppm	8pF	40 Ohm
ECS-400-8-36CKM	ECX-2236	MHz Crystal	40MHz	±10ppm	±10ppm	8pF	40 Ohm
ECS-480-8-36CKM	ECX-2236	MHz Crystal	48MHz	±10ppm	±10ppm	8pF	40 Ohm
ECS-800-8-36CKM	ECX-2236	MHz Crystal	80MHz	±10ppm	±10ppm	8pF	40 Ohm
ECS-.327-12.5-17-TR	ECX-306	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	12.5pF	50 kOhm
ECS-.327-6-17-TR	ECX-306	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	6pF	50 kOhm
ECS-.327-12.5-17X-C-TR	ECX-306X	kHz Crystal (Tuning Fork)	32.768kHz	-	±10ppm	12.5pF	50 kOhm
ECS-.327-12.5-17X-TR	ECX-306X	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	12.5pF	50 kOhm
