ECS-100-S-20A-TR,ECS伊西斯石英贴片晶振,CSM-8无源晶振

原厂型号 Original model ：	ECS-100-S-20A-TR
品牌 brand ：	ECS伊西斯晶振
型号名称 Model name：	CSM-8
Type 系列：	MHz Crystal
频率 frequency ：	10MHz
Frequency Stability频率稳定度	±50ppm
frequency tolerance频率容差	±30ppm
Load capacitance 负载电容	Series
Size / Dimension 尺寸	7050石英晶振

订购热线：0755-27838351

ECS-100-S-20A-TR,ECS伊西斯石英贴片晶振,CSM-8无源晶振

原厂型号 Original model ：	ECS-100-S-20A-TR	品牌 brand ：	ECS伊西斯晶振
品牌 brand ：	ECS伊西斯晶振	ESR（等效串联电阻）ESR (Equivalent Series Resistance)	60 Ohm
型号名称 Model name：	CSM-8欧美进口晶振	温度 Operating Temperature	-10°C ~ 70°C
Type 系列：	MHz Crystal	脚位 Termination：	2 pad
频率 frequency ：	10MHz	封装类型 Package Type：	2-SMD
Frequency Stability频率稳定度	±50ppm	高度 Package Height：	1.70mm
frequency tolerance频率容差	±30ppm	最小包装数 MPQ ：	-
Load capacitance 负载电容	Series	包装 Packaging：	Tape and Reel
Size / Dimension 尺寸	7.00mm x 5.00mm	安装方式 Mounting Style：	Surface Mount

ECS-100-S-20A-TR,ECS伊西斯石英贴片晶振,CSM-8无源晶振

ECS-100-S-20A-TR	CSM-8	MHz Crystal	10MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-110.5-20-20A-TR	CSM-8	MHz Crystal	11.0592MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-110.5-S-20A-TR	CSM-8	MHz Crystal	11.0592MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-120-20-20A	CSM-8	MHz Crystal	12MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-120-20-20A-TR	CSM-8	MHz Crystal	12MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-120-S-20A-TR	CSM-8	MHz Crystal	12MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-122.8-20-20A-TR	CSM-8	MHz Crystal	12.288MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-143-20-20A-TR	CSM-8	MHz Crystal	14.31818MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-143-S-20A-TR	CSM-8	MHz Crystal	14.31818MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-147.4-S-20A-TR	CSM-8	MHz Crystal	14.7456MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-160-20-20A-TR	CSM-8	MHz Crystal	16MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-160-S-20A-TR	CSM-8	MHz Crystal	16MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-184-S-20A-TR	CSM-8	MHz Crystal	18.432MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-196.6-S-20A-TR	CSM-8	MHz Crystal	19.6608MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-200-20-20A-TR	CSM-8	MHz Crystal	20MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-200-20-20B-TR	CSM-8	MHz Crystal	20MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-200-S-20A-TR	CSM-8	MHz Crystal	20MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-240.0014S20A-TR	CSM-8	MHz Crystal	24.00014MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-240-12-20A-TR	CSM-8	MHz Crystal	24MHz	±50ppm	±30ppm	12pF	40 Ohm
ECS-240-20-20A-TR	CSM-8	MHz Crystal	24MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-240-S-20A-TR	CSM-8	MHz Crystal	24MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-270-20-20A-F	CSM-8	MHz Crystal	27MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-300-S-20A-F-TR	CSM-8	MHz Crystal	30MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-300-S-20A-TR	CSM-8	MHz Crystal	30MHz	±50ppm	±30ppm	Series	80 Ohm
ECS-320-S-20A-F-TR	CSM-8	MHz Crystal	32MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-320-S-20A-TR	CSM-8	MHz Crystal	32MHz	±50ppm	±30ppm	Series	80 Ohm
ECS-330-S-20A-TR	CSM-8	MHz Crystal	33MHz	±50ppm	±30ppm	Series	80 Ohm
ECS-352.512-S20AF-TR	CSM-8	MHz Crystal	35.2512MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-360-20-20A-F	CSM-8	MHz Crystal	36MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-360-S-20A-F-TR	CSM-8	MHz Crystal	36MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-360-S-20A-TR	CSM-8	MHz Crystal	36MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-400-S-20A-F-TR	CSM-8	MHz Crystal	40MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-400-S-20A-TR	CSM-8	MHz Crystal	40MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-403.2-S-20A-TR	CSM-8	MHz Crystal	40.32MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-480-20-20A-TR	CSM-8	MHz Crystal	48MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-80-20-20A-TR	CSM-8	MHz Crystal	8MHz	±50ppm	±30ppm	20pF	-
ECS-98.3-20-20A-TR	CSM-8	MHz Crystal	9.8304MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-98.3-S-20A-TR	CSM-8	MHz Crystal	9.8304MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-120-20-20BM-TR	CSM-8M	MHz Crystal	12MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-98.3-20-20BM-TR	CSM-8M	MHz Crystal	98.3MHz	±50ppm	±30ppm	20pF	80 Ohm
ECS-100-18-20BQ-DS	CSM-8Q	MHz Crystal	10MHz	±100ppm	±30ppm	18pF	60 Ohm
ECS-110.5-18-20BQ-DS	CSM-8Q	MHz Crystal	11.0592MHz	±100ppm	±30ppm	18pF	60 Ohm
ECS-120-18-20BQ-DS	CSM-8Q	MHz Crystal	12MHz	±100ppm	±30ppm	18pF	60 Ohm
ECS-160-18-20BQ-DS	CSM-8Q	MHz Crystal	16MHz	±100ppm	±30ppm	18pF	40 Ohm
ECS-200-18-20BQ-DS	CSM-8Q	MHz Crystal	20MHz	±100ppm	±30ppm	18pF	40 Ohm
ECS-240-18-20BQ-DS	CSM-8Q	MHz Crystal	24MHz	±100ppm	±30ppm	18pF	40 Ohm
ECS-250-18-20BQ-DS	CSM-8Q	MHz Crystal	25MHz	±100ppm	±30ppm	18pF	40 Ohm
ECS-80-18-20BQ-DS	CSM-8Q	MHz Crystal	8MHz	±100ppm	±30ppm	18pF	60 Ohm
ECS-.327-8-14	ECS-1x5	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	8pF	40 kOhm
ECS-.327-8-14X	ECS-1x5X	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	8pF	40 kOhm
ECS-.327-12.5-13	ECS-2x6	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	12.5pF	35 kOhm
ECS-.327-6-13	ECS-2x6	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	6pF	35 kOhm
ECS-.327-12.5-13FLX-C	ECS-2x6-FLX	kHz Crystal (Tuning Fork)	32.768kHz	-	±10ppm	12.5pF	50 kOhm
ECS-.327-12.5-13X	ECS-2X6X	kHz Crystal (Tuning Fork)	32.768kHz	-	±20ppm	12.5pF	35 kOhm
ECS-.320-12.5-13	ECS-31	kHz Crystal (Tuning Fork)	32kHz	-	±30ppm	12.5pF	-
ECS-.400-12.5-13	ECS-31	kHz Crystal (Tuning Fork)	40kHz	-	±30ppm	12.5pF	-
ECS-.600-12.5-13	ECS-31	kHz Crystal (Tuning Fork)	60kHz	-	±30ppm	12.5pF	-
ECS-.655-12.5-13	ECS-31	kHz Crystal (Tuning Fork)	65.536kHz	-	±30ppm	12.5pF	-
ECS-.750-12.5-13	ECS-31	kHz Crystal (Tuning Fork)	75kHz	-	±30ppm	12.5pF	-
ECS-1.00-12.5-13	ECS-31	kHz Crystal (Tuning Fork)	100kHz	-	±30ppm	12.5pF	-
