ECS-100A-200有源晶振,ECS插件晶振,ECS-100石英晶振
| 原厂型号 Original model ： | ECS-100A-200 |
| Manufacturer品牌 | ECS有源晶振 |
| Series型号 | ECS-100 |
| Type 类型 | XO (Standard) |
| Frequency 频率 | 20MHz |
| 输出方式 Output： | TTL |
| Voltage - Supply电压 | 5V有源振荡器 |
| Frequency Stability频率稳定度 | ±100ppm |
| Size / Dimension 尺寸 | 20.86mm x 13.20mm |
订购热线：0755-27838351
ECS-100A-200有源晶振,ECS插件晶振,ECS-100石英晶振
| 原厂型号 Original model ： | ECS-100A-200 | 品牌 brand ： | - |
| Manufacturer品牌 | ECS有源晶振 | Operating Temperature温度 | 0°C ~ 70°C |
| Series型号 | ECS-100 | Current - Supply (Max) | 30mA |
| Type 类型 | XO (Standard) | Package Height高度 | 5.08mm |
| Frequency 频率 | 20MHz | Termination 脚位 | 4 pad |
| 输出方式 Output： | TTL有源晶振 | Package Type 封装类型 | 14-DIP |
| Voltage - Supply电压 | 5V | Packaging 包装 | Tape and Reel |
| Frequency Stability频率稳定度 | ±100ppm | 安装方式 Installation ： | Surface mount |
| Size / Dimension 尺寸 | 20.86mm x 13.20mm | 最小包装数 MPQ ： | - |
ECS-100A-200有源晶振,ECS插件晶振,ECS-100石英晶振
| ECS-100A-200 | ECS-100 | XO (Standard) | 20MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-283.2 | ECS-100 | XO (Standard) | 28.322MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-180 | ECS-100 | XO (Standard) | 18MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-162.5 | ECS-100 | XO (Standard) | 16.257MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-325.1 | ECS-100 | XO (Standard) | 32.514MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-010 | ECS-100 | XO (Standard) | 1MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-080 | ECS-100 | XO (Standard) | 8MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-049 | ECS-100 | XO (Standard) | 4.9152MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-040 | ECS-100 | XO (Standard) | 4MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-160 | ECS-100 | XO (Standard) | 16MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-250 | ECS-100 | XO (Standard) | 25MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-051 | ECS-100 | XO (Standard) | 5.0688MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-018 | ECS-100 | XO (Standard) | 1.8432MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-196.6 | ECS-100 | XO (Standard) | 19.6608MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-020 | ECS-100 | XO (Standard) | 2MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-480 | ECS-100 | XO (Standard) | 48MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-100 | ECS-100 | XO (Standard) | 10MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-400 | ECS-100 | XO (Standard) | 40MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-073 | ECS-100 | XO (Standard) | 7.3728MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-184 | ECS-100 | XO (Standard) | 18.432MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-143 | ECS-100 | XO (Standard) | 14.31818MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-012.2 | ECS-100 | XO (Standard) | 1.2288MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-050 | ECS-100 | XO (Standard) | 5MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-036 | ECS-100 | XO (Standard) | 3.6864MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-147.4 | ECS-100 | XO (Standard) | 14.7456MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-120 | ECS-100 | XO (Standard) | 12MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-240 | ECS-100 | XO (Standard) | 24MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-320 | ECS-100 | XO (Standard) | 32MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-060 | ECS-100 | XO (Standard) | 6MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-061 | ECS-100 | XO (Standard) | 6.144MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-251.7 | ECS-100 | XO (Standard) | 25.175MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-500 | ECS-100 | XO (Standard) | 50MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-098.3 | ECS-100 | XO (Standard) | 9.8304MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-350 | ECS-100 | XO (Standard) | 35MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-092.1 | ECS-100 | XO (Standard) | 9.216MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-035 | ECS-100 | XO (Standard) | 3.579545MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-640 | ECS-100 | XO (Standard) | 64MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-110.5 | ECS-100 | XO (Standard) | 11.0592MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100A-300 | ECS-100 | XO (Standard) | 30MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100A-024 | ECS-100 | XO (Standard) | 2.4576MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100A-666 | ECS-100 | XO (Standard) | 66.666MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100AX-040 | ECS-100X | XO (Standard) | 4MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100AX-020 | ECS-100X | XO (Standard) | 2MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100AX-147.4 | ECS-100X | XO (Standard) | 14.7456MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100AX-160 | ECS-100X | XO (Standard) | 16MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100AX-010 | ECS-100X | XO (Standard) | 1MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100AX-200 | ECS-100X | XO (Standard) | 20MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100AX-500 | ECS-100X | XO (Standard) | 50MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100AX-110.5 | ECS-100X | XO (Standard) | 11.0592MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100AX-018 | ECS-100X | XO (Standard) | 1.8432MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100AX-640 | ECS-100X | XO (Standard) | 64MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100AX-100 | ECS-100X | XO (Standard) | 10MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100AX-060 | ECS-100X | XO (Standard) | 6MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100AX-184 | ECS-100X | XO (Standard) | 18.432MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100AX-320 | ECS-100X | XO (Standard) | 32MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100AX-061 | ECS-100X | XO (Standard) | 6.144MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100AX-098.3 | ECS-100X | XO (Standard) | 9.8304MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 30mA |
| ECS-100AX-036 | ECS-100X | XO (Standard) | 3.6864MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 15mA |
| ECS-100AX-300 | ECS-100X | XO (Standard) | 30MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
| ECS-100AX-480 | ECS-100X | XO (Standard) | 48MHz | TTL | 5V | ±100ppm | 0°C ~ 70°C | 70mA |
ECS-100A-200有源晶振,ECS插件晶振,ECS-100石英晶振
